Easy-Start ES Instruction Manual
Drawings
INSTALLATION
2-31
NOTES
1. PANEL MATERIAL: 14 GA (.074) STEEL
FINISH: ASA 61 LIGHT GRAY
2. PANEL SHOULD BE MOUNTED IN A VERTICAL
POSITION TO PROVIDE PROPER COOLING.
3. WHEN DAUGHTER BD. OPTION IS USED DEPTH
IS 7.50".
FIELD WIRING LUGS
WIRE GAUGE RANGE
LINE / LOAD LUGS
AWG 14-1 0 AWG 14-2
50
GROUND LUGS
MODEL
ES070-_EC
WEIGHT
LBS
2.00
3.75
13.69
6.25
0.00
13.25
10.13
.219
DIA.
3.88
.75
0
0
.50
3.42 4.50 9.63
DWG NO 3D17438
14.63 14.75 15.00
.31
.68
#4 AWG
(6´ FT LG)
14.00
B
B B
B
B
B
B
BBB
B
B
B
#4 AWG
(6´ FT LG)
Easy ES--012
Dimension and Installation Open Panel Slim Line Motor Control Center ES070-_EC
Figure 2-12
