6. Function blocks
6.1 Manufacturer function blocks
Example 5: Select time range
The year time switch HY01 is required to switch on at 00:00 on day 01.05 of each year
and stay on continuously until 00:00 on 2.11 of each year.
The HY year time switch must be assigned the following parameters:
Programming view/HY01/Year time switch parameters tab
Figure 111: Figure: Entry screen in the programming software
Example 6: Specific days of specific months
The year time switch HY01 is required to switch on at 0:00 on day 9 of months 6, 7, 8, 9
and 10 of each year and switch off at 00:00 on day 17 of the month.
The HY year time switch must be assigned the following parameters:
Programming view/HY01/Year time switch parameters tab
Figure 112: Figure: Entry screen in the programming software
