1. easyE4 control relays description
1.8 Overview of devices
1.8 Overview of devices
EASY-E4-...-12...C1 EASY-E4-...-12...CX1
Expansions
Power Supply Pushbuttons LED POW/RUN
Input points Slot for microSD
memory card
LED
ETHERNET/NET
Outputs Covering cap Bus connector
plug
Ethernet con-
nection
Functional
earth
Display Analog inputs
Ethernet
socket
Cursor buttons Analog outputs
easyE4 11/18 MN050009 EN www.eaton.com
