Eaton EDR-5000 Installation, Operation And Maintenance

EDR-5000 IM02602007E
Signals of the Statistics Module
Signal Description
ResFc all Signal: Resetting of all Statistic values (Current Demand, Power Demand, Min, Max)
ResFc I Demand Signal: Resetting of Statistics - Current Demand (avg, peak avg)
ResFc P Demand Signal: Resetting of Statistics - Power Demand (avg, peak avg)
ResFc Max Signal: Resetting of all Maximum values
ResFc Min Signal: Resetting of all Minimum values
Counters of the Module Statistics
Value Description Menu path
Res Cr I Demand Number of resets since last booting. The timestamp shows date and
time of the last reset.
[Operation
/Statistics
/Demand
/Current Demand]
Res Cr P Demand Number of resets since last booting. The timestamp shows date and
time of the last reset.
[Operation
/Statistics
/Demand
/Power Demand]
Res Cr Min values Number of resets since last booting. The timestamp shows date and
time of the last reset.
[Operation
/Statistics
/Min
/Power]
Res Cr Max values Number of resets since last booting. The timestamp shows date and
time of the last reset.
[Operation
/Statistics
/Max
/Power]
www.eaton.com 198
