EDR-5000 IM02602007E
Assignment List
The »ASSIGNMENT LIST« below summarizes all module outputs (signals) and inputs (e.g.: states of the assignments).
Name Description
-.- No assignment
Prot.Available Signal: Protection is available.
Prot.Active Signal: Active
Prot.ExBlo Signal: External Blocking
Prot.Pickup Phase A Signal: General Pickup Phase A
Prot.Pickup Phase B Signal: General Pickup Phase B
Prot.Pickup Phase C Signal: General Pickup Phase C
Prot.Pickup IX or IR Signal: General Pickup - Ground Fault
Prot.Pickup Signal: General Pickup
Prot.Trip Phase A Signal: General Trip Phase A
Prot.Trip Phase B Signal: General Trip Phase B
Prot.Trip Phase C Signal: General Trip Phase C
Prot.Trip IX or IR Signal: General Trip Ground Fault
Prot.Trip Signal: General Trip
Prot.Res Fault a Mains No Signal: Resetting of fault number and number of grid faults.
Prot.I dir fwd Signal: Phase current failure forward direction
Prot.I dir rev Signal: Phase current failure reverse direction
Prot.I dir n poss Signal: Phase fault - missing reference voltage
Prot.IR dir fwd Signal: IR Ground fault (calculated) forward
Prot.IR dir rev Signal: IR Ground fault (calculated) reverse direction
Prot.IR dir n poss Signal: IR Ground fault (calculated) direction detection not possible
Prot.IX dir fwd Signal: IX Ground fault (measured) forward
Prot.IX dir rev Signal: IX Ground fault (measured) reverse direction
Prot.IX dir n poss Signal: IX Ground fault (measured) direction detection not possible
Prot.ExBlo1-I Module Input State: External Blocking1
Prot.ExBlo2-I Module Input State: External Blocking2
Ctrl.Local Switching Authority: Local
Ctrl.Remote Switching Authority: Remote
Ctrl.SG Indeterm Minimum one Switchgear is moving (Position cannot be determined).
Ctrl.SG Disturb Minimum one Switchgear is disturbed.
Bkr.SI SingleContactInd Signal: The Position of the Switchgear is detected by one auxiliary contact (pole) only. Thus indeterminate
and disturbed Positions cannot be detected.
Bkr.Pos not CLOSE Signal: Pos not CLOSE
www.eaton.com 949
