User Menu Options
Page 43
Wired Sirens Wired sirens and their strobes.
Loudspeakers Extension loudspeakers.
Wired Keypads Sounders in wired keypads.
KEY-RKPZ Sounders in KEY-RKPZ two-way radio keypads.
Internal Sounders SDR-RINT internal radio sounders.
3. Press or to select whether to operate all sirens\sounders of the
selected type, or (for partitioned system only) only those assigned to a
specific partition. Press to switch the sirens\sounders on, and
again to switch them off.
4. Press to finish the test.
Testing a wired keypad
Note: You can test only the keypad you are currently using (you cannot
test a keypad remotely).
To carry out the test:
1. Select Test Wired Keypad.
The bottom line of the display shows the keypad name and bus
address. For example:


All four ABCD LEDs and LEDs around the navigation keys should
glow red.
2. Press , , and in turn to test the navigation keys. Each time
you press a key, the LEDs should change colour and the display show
the key you pressed.
3. Press both HUA keys at the same time. The display should confirm
that you pressed the HUA keys. An HUA alarm is not generated.
4. Press any other key to test it. The display should confirm the key you
pressed.
5. Press to finish the test.
