Eaton Matrix 2000 User Manual

Appendix A
Specifications


Copyright © 2017 Eaton Corporation. All Rights Reserved.
IPN 997-00012-72C July 2017
19
A p p e n d i x A
Specifications
DC Input
Connector
1/4" studs, 5/8" spacing to suit 2-hole crimp lugs
(not included)
Nominal voltage
48V dc
Operating range
40 – 60V dc
Maximum input current
56A
Under voltage warning threshold
45V dc
Under voltage threshold
40V dc
Over voltage warning threshold
58V dc
Over voltage threshold
60V dc
Inrush current
<2*I
rated
Isolation DC-enclosure
707V dc (Varistors and filter capacitor
removed)/1min
Input protection
Reverse Polarity Protection
Psophometric noise voltage
≤1.0mV ITU-T O.41 (16.66 ~ 6000Hz)
Wide Band Noise
<1.0mV psof (25Hz~5kHz)
<20mV rms (25Hz~20kHz)
Peak to peak noise
150mV up to 100MHz
AC Input (with Transfer Switch)
Connector
120V models:
Cord (2.2m/7 ft) with NEMA 5-20P
230V models:
IEC 320-C20 plug to suit IEC 320-C19 socket (not
included)
Voltage Range
110/115/120V ac: 89 – 138V ac
208/220/230/240V ac: 176 – 276V ac
Frequency Range
50/60Hz ± 2.5%
Nominal input current (maximum)
110/115/120V ac: 19A
208/220/230/240V ac: 10A
Over Voltage Threshold
138/276V ac
Under Voltage Threshold
89/176V ac
Transfer Time
Inverter to utility ac: 8ms
Utility ac to inverter: 10ms
