Eaton Matrix 2000 User Manual

Matrix Standalone Inverter
20
Copyright © 2017 Eaton Corporation. All Rights Reserved.
IPN 997-00012-72C July 2017
AC Output
Connectors
120V models:
2 x NEMA 5-20R sockets to suit NEMA 5-20P
plugs (not included)
230V models:
2 x IEC 320-C13 sockets to suit IEC 320-C14 plugs
(not included)
Power Capacity
2000VA/2000W
Waveform
Pure sine wave
Power factor
1.0
Nominal output voltage
110/115/120V ac or 208/220/230/240V ac
Nominal output current (maximum)
110/115/120V ac: 18.2A
208/220/230/240V ac: 9.6A
Voltage regulation
±2%
Output frequency
50/60Hz
Frequency variation
±0.5%
Frequency setting
Manually, field selectable
Crest factor
3:1
THD
<3% for linear load
<5% for non-linear load
Capacitive/inductive load
-1.0 to +1.0 without exceeding permissible
distortion for resistive load
Efficiency
120V ac model: >90.5%
230V ac model: >91%
Current limitation
Electronic current limitation at overloads and short
circuits.
Isolation AC-enclosure
Basic isolation (Pri-Gnd) 2121V dc/1min
Isolation AC-DC
Reinforced isolation (Pri-Sec) 4242V dc/1min
Surge protection
EN61000-4-5.
Telcordia GR-1089 Core ANSI C62.41-IEEE, STD
587-1980
Dynamic response
<±10%, according to IEC 62040-3 class 1
Over load protection
1.2*I
nom
permanent overload capacity @ 30ºC.
1.5*I
nom
, 10s max
2*I
nom
, 5s
Mechanical
Dimension (D, W, H)
360mm*, 19" mount/440mm, 1U/44mm
(14.2", 17.3", 1.7")
*Additional space required for ventilation.
Weight
120V ac model: 7.6kg (16.7 lb)
230V ac model: 7.4kg (16.3 lb)
