Appendix A
162 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Quick Start Parameter Guide, continued (Full parameter guide begins on Page 161)
System Parameters in the Quick Start
Notes
Factory settings dependent on specific drive selected.
These parameters are overwritten with the bus-specific parameters when a fieldbus connection (for example, CANopen) is used.
The parameter values described in the manual of the fieldbus interface then apply.
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P7.1 113 X rw Motor, rated operational current 0.2 x I
e
–2 x I
e
(see motor rating plate)
89 I
e
P7.3 112 X rw Motor, rated speed 300–20000 RPM
(see motor rating plate)
89 1720
P7.4 120 X rw Motor, power factor
(cos )
0.30–1.00
(
see motor rating plate)
89 0.85
P7.5 110 X rw Motor, rated operating voltage 180– 500V
(see motor rating plate)
89
P7.6 111 X rw Motor, rated frequency 30–320 Hz
(see motor rating plate)
89 60.00
P11.7 109 X rw Torque increase 0 = Deactivated
1 = Enabled
109 0
M1.1 1Xro Output frequency Hz 127 0.00
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
S1.1 833 X ro API SW ID 125
S1.2 834 X ro API SW Version 125
S1.3 835 X ro Power SW ID 125
S1.4 836 X ro Power SW Version 125
S1.5 837 X ro Application ID 125
S1.6 838 X ro Application revision 125
S1.6 838 X ro System load 125
S2.1
808 X ro Communication status RS485 in xx.yyy format
xx = Number of error messages
(0–64)
yyy = Number of correct messages
(0–999)
125
S2.2
809 rw Fieldbus protocol 0 = FB disabled
1 = Modbus
125 0
S2.3
810 rw Slave address 1–255 125 1
S2.4
811 rw Baud rate 0 = 300
1 = 600
2 = 1200
3 = 2400
4 = 4800
5 = 9600
125 5
