Appendix A
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 169
Drives Control, continued
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P6.13 731 X rw REAF, automatic restart after an
error message
0 = Deactivated
1 = Activated
85 0
P6.14 1600 X rw Stop on direction change via the
arrow buttons (</>) of the keypad
(KEYPAD)
0 = Deactivated
1 = Activated
85 1
P6.15 184 X rw Keypad frequency reference (REF) –P6.4 – +P6.4 Hz 86 0.00
P6.16 1474 X rw Stop button active 0 = Deactivated (no)
1 = Activated (yes)
86 1
P6.17 1427 X rw Secondary remote control source 1 = Control signal terminals (I/0)
2 = Control unit (KEYPAD)
3 = Fieldbus (BUS)
86 3
P6.18 1428 X rw Secondary remote speed reference 0 = Fixed frequency (FF0)
1 = Operating unit (REF)
2 = Fieldbus (BUS)
3 = AI1
4 = AI2
5 = Motor potentiometer
86 2
P6.19 502 X rw Secondary acceleration time
(acc2)
0.1–3000s 86 10.0
P6.20 503 X rw Secondary deceleration time
(dec2)
0.1–3000s 86 10.0
P6.21 526 X rw Acceleration transition frequency
(acc1–acc2)
0.00–P6.4 Hz 86 0.00
P6.22
1334 X rw Deceleration transition frequency
(dec1–dec2)
0.00–P6.4 Hz 86 0.00
P6.23 1429
X rw REV blocked 0 = Deactivated
1 = Activated
86 0
P6.24 509 X rw Skip frequency
1, lower value 0.00–P6.25 87 0.00
P6.25 510 X rw Skip frequency 1, upper value P6.24–P6.4 Hz 87 0.00
P6.26 511 X rw Skip frequency 2, lower value 0.00–P6.27 87 0.00
P6.27 731 X rw Skip frequency 2, upper value P6.26–P6.4 Hz 87 0.00
P6.28 513 X rw Skip frequency 3, lower value 0.00–P6.29 87 0.00
P6.29 514 X rw Skip frequency 3, upper value P6.28–P6.4 Hz 87 0.00
P6.30 759 X rw Automatic REAF attempts 1–10 87 3
P6.31 1481 X rw Manual mode, primary control
source
1 = Control signal terminals (I/0)
2 = Control unit (KEYPAD)
3 = Fieldbus (BUS)
87 1
P6.32 1482 X rw Manual mode, primary speed
reference
0 = Fixed frequency (FF0)
1 = Operating unit (REF)
2 = Fieldbus (BUS)
3 = AI1
4 = AI2
5 = Motor potentiometer
87 3
P6.33 1483 X rw Manual mode, KEYPAD lock 0 = Deactivated
1
= Activated
87 1
