Eaton MMX34AA3D3F0-0 User Manual

Installation
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 37
Arrangement and Size of the Connection Terminals, continued
Part
Numbers mm
2
AWG mm in Nm ft-lbs mm Terminal Configuration
FS3 MMX11AA4D8_ 0.2–4 24–10 8 0.31 0.5–0.6 0.37–0.44 0.6 x 3.5
MMX12AA9D6_ 0.2–4 24–10 8 0.31 0.5–0.6 0.37–0.44 0.6 x 3.5
MMX32AA011_ 0.2–4 24–10 8 0.31 0.5–0.6 0.37–0.44 0.6 x 3.5
MMX34AA7D6_
MMX34AA9D0_
MMX34AA012_
MMX34AA014_
0.2–4 24–10 8 0.31 0.5–0.6 0.37–0.44 0.6 x 3.5
FS4 MMX32AA017_
MMX32AA025_
0.5–16 20–6 8 0.39 1.2–1.5 0.88–1.11 0.6 x 3.5
MMX34AA016_
MMX34AA023_
0.5–16 20–6 8 0.39 1.2–1.5 0.88–1.11 0.6 x 3.5
FS5 MMX32AA031_
MMX32AA038_
0.5–16 20–6 8 0.39 1.2–1.5 0.88–1.11 0.6 x 3.5
MMX34AA031_
MMX34AA038_
0.5–16 20–6 8 0.39 1.2–1.5 0.88–1.11 0.6 x 3.5
M3
L3
L2/N
U/T1
V/T2
W/T3
L1
L2/N
U/T1
V/T2
W/T3
L1
L2/N
U/T1
V/T2
W/T3
L3
L1
L2/N
U/T1
V/T2
W/T3
L3
R+ R–
L1
L2
U/T1
V/T2
W/T3
L3
DC+/R+ R- DC-
L1
L2
U/T1
V/T2
W/T3
L3
DC+/R+ R- DC-
L1
L2
U/T1
V/T2
W/T3
L3
DC+/R+ R- DC-
L1
L2
U/T1
V/T2
W/T3
L3
DC+/R+ R- DC-
