Parameters
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 65
Quickstart Wizard
The quick start assistant guides you in the quick
configuration through all important settings that have to be
made or that you should check for your application (see A in
figure on Page 64). The parameters that are called during the
process are listed in the table on Page 66, in the “Basic
(Standard Drive)” column.
The process is run from parameter to parameter. Returning is
not possible here.
When the quick configuration is completed, the frequency
display M1.1 is activated automatically. Selecting the PAR
main menu again enables you to call up the parameters of
the quick configuration and then change them freely.
Besides the parameters of the quick configuration, system
parameters S1.1 to S4.3 are also shown after the first
setting.
P1.1 = 0 activates access to all parameters and the full
functionality of all buttons of the keypad (free parameter
definition, see B in the figure on Page 64).
This exits the quick configuration and the guided setup with
the quick start assistant.
In the quick configuration, the OK button activates
the individual parameter values and then moves on
to the next parameter. Every parameter always
shows the value that is set in alternating sequence.
By actuating the OK button again, you activate the
value (value flashes).
The arrow buttons have restricted
functionality (change of parameter values
and cursor control) in the quick start
configuration.
OK
