M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 81
Digital Outputs, continued
PNU ID
Access
RUN Value/Range Description
Factory Setting
(P1.3)
P5.8 1457 — Current monitoring 0.00
0.00–P7.2
(I
e
A)
Activate output if current value reaches value selected
(P7.2 = current limit)
A monitoring message can be implemented via the digital
outputs (P5.1, P5.2, P5.3 = 27)
P5.9 1458 — DO logic (control signal terminal 13) 0
Operation of transistor output DO–
0 N/O contact
1 N/C contact
P5.10 1331 — RO1 logic (control signal terminals 22, 23) 0
Operation of relay contact R13/R14
0 N/O contact
1 N/C contact
P5.11 1332 — RO2 logic (control signal terminal 24, 25, 26) 0
Operation of relay changeover contact
0 N/O contact (R21–R24) or N/C contact (R21–R22)
1 N/C contact (R21–R24) or N/O contact (R21–R22)
P5.12 1459 — DO, on delay 0.00
0.00–320.00s —
P5.13 1460 — DO, off-delay 0.00
0.00–320.00s —
P5.14 1461 — RO1, on delay 0.00
0.00–320.00s —
P5.15 1424 — RO1, off-delay 0.00
0.00–320.00s —
P5.16 1425 — RO2, on delay 0.00
0.00–320.00s —
P5.17 1426 — RO2, off-delay 0.00
0.00–320.00s —
