Eaton MP-3000 User Manual

Effective 10/02
Page 4-15
For more information visit: www.cutler-hammer.eaton.com
Page 4-15
IL17562BH04
Selected
Value
Line
No.
6
7
8
9
10
11
12
13
14
15
16
17
18
Display
Choose:
UB A ON
UB T ON
or
UB OFF
Choose:
WD A ON
WD T ON
or
WD OFF
Choose:
MB A ON
MB T ON
or
MB OFF
Choose:
LB A ON
LB T ON
or
LB OFF
Choose:
AX A ON
AX T ON
or
AX OFF
Choose:
SX A ON
SX T ON
or
SX OFF
Choose:
TBS T ON
or
TBS OFF
RTDF ON
or
RTDF OFF
RCOM ON
or
RCOM OFF
IOC A ON
IOC T ON
or
IOC OFF
PH R ON
or
PH R OFF
INSQ ON
or
INSQ OFF
REMT ON
or
REMT OFF
Help Message
ENABLE PHASE UNBALANCE ALARM
OR TRIP TO ACTIVATE AUX2 RELAY
OUTPUT OR DISABLE
ENABLE WINDING TEMP ALARM OR
TRIP TO ACTIVATE AUX2 RELAY
OUTPUT OR DISABLE
ENABLE MOTOR BEARING TEMP
ALARM OR TRIP TO ACTIVATE AUX2
RELAY OUTPUT OR DISABLE
ENABLE LOAD BEARING TEMP ALARM
OR TRIP TO ACTIVATE AUX2 RELAY
OUTPUT OR DISABLE
ENABLE AUXILIARY RTD TEMP ALARM
OR TRIP TO ACTIVATE AUX2 RELAY
OUTPUT OR DISABLE
ENABLE STARTS PER TIME TRIP OR
ALARM TO ACTIVATE AUX2 RELAY
OUTPUT OR DISABLE
ENABLE TIME BETWEEN STARTS TRIP
OR TO ACTIVATE AUX2 RELAY OUTPUT
OR DISABLE
ENABLE RTD FAILURE DIAGNOSTIC TO
ACTIVATE AUX2 RELAY OUTPUT OR
DISABLE
ENABLE RTD MODULE
COMMUNICATION FAILURE TO ACTIVATE
AUX2 RELAY OUTPUT OR DISABLE
ENABLE INSTANTANEOUS
OVERCURRENT ALARM OR TRIP TO
ACTIVATE AUX2 RELAY OUTPUT
OR DISABLE
ENABLE PHASE REVERSAL TRIP TO
ACTIVATE AUX2 RELAY OUTPUT
OR DISABLE
ENABLE INCOMPLETE SEQUENCE TRIP
TO ACTIVATE AUX2 RELAY OUTPUT OR
DISABLE
ENABLE REMOTE TRIP TO ACTIVATE
AUX2 RELAY OUTPUT OR DISABLE
Setting
Range/ Value
Selection
Toggles between
UB A ON, UB T
ON, and UB OFF
Toggles between
WD A ON, WD T
ON, and WD OFF
Toggles between
MB A ON, MB T
ON, and MB OFF
Toggles between
LB A ON, LB T
ON, and LB OFF
Toggles between
AX A ON, AX T
ON, and AX OFF
Toggles between
SX A ON, SX T
ON, and SX OFF
Toggles between
TBS T ON, and
TBS OFF
Toggles between
RTDF ON and
RTDF OFF
Toggles between
RCOM ON and
RCOM OFF
Toggles between
IOCT ON and
IOCT OFF
Toggles between
PH R ON and PH
R OFF
Toggles between
INSQ ON and
INSQ OFF
Toggles between
REMT ON and
REMT OFF
Value
as
shipped
UB OFF
WD OFF
MB OFF
LB OFF
AX OFF
SX OFF
TBS
OFF
RTDF OFF
RCOM
OFF
IOCT OFF
PH R OFF
INSQ OFF
REMT OFF
Section
Reference
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
5.10.2
