LOG STRT
Line
START X
Description
This page contains detailed informa-
tion about the last four motor starts.
Each of the last 4 starts are numbered
1 being the most recent and 4 being
the oldest. Press line up to get the
latest start line down to get the oldest
start.
The date of start
The time of start
Highest of each phase current in amps
during start
The highest ground fault current in
amps during start
The highest percent sequence current
unbalance during start
The average current of all three
phases in amps at start transition
The elapsed time from start to current
below the transition current set point
level
Complete Help Message
MOTOR BEARING TEMP 2 IN
DEGREES (F OR C) AT TIME OF EVENT
LOAD BEARING TEMP 1 IN DEGREES
(F OR C) AT TIME OF EVENT
LOAD BEARING TEMP 2 IN DEGREES
(F OR C) AT TIME OF EVENT
AUXILIARY TEMP IN DEGREES
(F OR C) AT TIME OF EVENT
DETAILED LOG OF THE LAST 4 STARTS
START NUMBER MOST RECENT
START EQUAL 1
DATE OF EVENT
TIME OF EVENT
MAXIMUM PHASE A CURRENT
DURING START
MAXIMUM PHASE B CURRENT
DURING START
MAXIMUM PHASE C CURRENT
DURING START
MAXIMUM GROUND FAULT CURRENT
DURING START
MAXIMUM PHASE UNBALANCE
DURING START
AVERAGE CURRENT AT TIME OF
TRANSITION IN AMPS
TIME FROM START TO CURRENT
TRANSITION IN SECONDS
TIME FROM START TO RUN OR TRIP
IN SECONDS
Display
MT2 XXX
LT1 XXX
LT2 XXX
AXT XXX
MM/DD/YY
HH.MM
IA XXX
IB XXX
IC XXX
IG XXX
UB XXX
ITR XXX
TSTI XXX
TSTR XXX
