SPECIFICATIONS
EATON Powerware
®
9155 UPS (8–15 kVA) User’s Guide S 164201553 Rev F www.powerware.com
75
Table 15. Technical Specifications
Technology Online, double-conversion, split-phase topology with static bypass switch and
optional 3-position maintenance bypass switch.
Frequency independent operation.
Input Voltage Range 75–144 Vac per phase
Input Isolation
Transformer Input
Voltage Range
208V or 240V ±20%
Input Power Factor >0.99 at full load nominal line conditions
Input Rated Voltage 100/200, 110/220, or 120/240 Vac with 180° phase displacement
120/208 or 127/220 Vac with 120° phase displacement
Input Frequency Range 45–65 Hz
Input Rated Frequency 50/60-Hz selectable, auto-configuring
Output Voltage
Regulation
±1% static, Phase to Neutral
±2% static, P hase to Phase
±5% dynamic at 100% resistive load change
Response time <1 ms
Output Voltage
Distortion
<2% THD linear load
<5% THD non-linear load
Output Frequency 50/60-Hz selectable or auto-configuring
Output Frequency
Regulation
Synchronization to line
Output Frequency
Conversion
Frequency/phase-converter operation with derated output load capacity to
80%; Frequency Conversion mode can be configured through the front panel
or through XCP commands.
Bypass is not available in Frequency Conversion mode.
Output Overload 101–110% for 10 minutes
111–125% for 60 seconds
126–149% for 5 seconds
>150% for 300 milliseconds
Table 16. Model Specifications
15 kVA Model
Output Voltage (Line–Line) 200 220 240 208 220
Output Voltage (Line–Neutral) 100 110 120 120 127
Input Current* 71A 71A 71A 71A 67A
Output Current 63A 63A 63A 63A 59A
Output kVA (Line–Line Loads) 12.5 13.8 15.0 13.0 13.0
Output kVA (Line–Neutral Loads) 12.5 13.8 15.0 15.0 15.0
Output kW 11.3 12.4 13.5 13.5 13.5
Output Peak Current 155 155 155 155 155
Efficiency (Minimum) 88% 88% 88% 88% 88%
Power Dissipation (BTU/hr) 5582 5582 5582 5582 5582
DC Voltage (Supply) 192 192 192 192 192
* Input current for the input isolation transformer is 4% higher than for the UPS.
