Appendix A—Parameters
S811+ Soft Starter MN03900001E—November 2012 47
Soft Start Config Menu
Soft Start Config—S811+ …N3S Standard
Soft Start Config Menu Units
Minimum
Inline
(InsideDelta)
Maximum
Inline
(InsideDelta)
Default
Inline
(InsideDelta) Notes
Access
Level
Mtr Nameplate FLA 2
S811+N37… Amps 11 (19) 37 (65) 11 (19) Motor FLA parameter must be set to motor
nameplate FLA to achieve proper overload
protection.
2
S811+N66… Amps 20 (35) 66 (114) 20 (35) 2
S811+R10… Amps 32 (55) 105 (182) 32 (55) 2
S811+R13… Amps 42 (73) 135 (234) 42 (73) 2
S811+T18… Amps 56 (97) 180 (311) 56 (97) 2
S811+T24… Amps 75 (130) 240 (415) 75 (130) 2
S811+T30… Amps 95 (164) 304 (526) 95 (164) 2
S811+U36… Amps 112 (195) 360 (623) 112 (195) 2
S811+U42… Amps 131 (227) 420 (727) 131 (227) 2
S811+U50… Amps 156 (270) 500 (865) 156 (270) 2
S811+V36… Amps 112 (195) 360 (623) 112 (195) 2
S811+V42… Amps 131 (227) 420 (727) 131 (227) 2
S811+V50… Amps 156 (270) 500 (865) 156 (270) 2
S811+V65… Amps 203 (352) 650 (1125) 203 (352) 2
S811+V72… Amps 225 (389) 720 (1246) 225 (389) 2
S811+V85… Amps 265 (458) 850 (1471) 265 (458) 2
S811+V10… Amps 312 (539) 1000 (1732) 312 (539) 2
Ovrld Trip Class 5 30 20 2
Phase Rev Fault 0 1 0 0 = Enabled
1 = Disabled
2
Phase Sequence 0 1 0 0 = ABC
1 = ACB
2
Start Method 0 2 0 0 = Voltage Ramp
1 = Current Limit
2
Initial Torque % 0 85 45 1
Soft Start Time Seconds 0.5 180 20 1
Kick Start Torq % 0 85 0 1
Kick Start Time Seconds 0 2 0 1
Soft Stop Time Seconds 0 60 0 1
Reset Mode 0 2 0 0 = Manual
1 = Auto
2 = Powerup Reset
2
Auto Reset Delay Seconds 0.1 600 0.1 2
Auto Reset Limit 0 10000 0 2
Motor Wiring Config 0 1 0 0 = Inline
1 = InsideDelta
2
