Appendix D—Ratings, Cooling and Power Losses—Inside-the-Delta
60 S811+ Soft Starter MN03900001E—November 2012
Appendix D—Ratings, Cooling and Power Losses—Inside-the-Delta
Power Ratings
Standard Duty—15 Second Ramp, 300% Current Limit at 40°C—Inside-the-Delta Connection
Notes
1.0SF = 1.0 Service Factor.
1.15SF = 1.15 Service Factor.
1
Consult factory.
Maximum
Continuous
Line Current
Three-Phase Motors
Catalog
Number
kW Rating (50 Hz) hp Rating (60 Hz)
230V 380–400V 440V 200V 230V 460V 575–690V
1.0SF 1.0SF 1.0SF 1.0SF 1.15SF 1.0SF 1.15SF 1.0SF 1.15SF 1.0SF 1.15SF
Frame Size N
65 1018.518.51515151540305050S811+N37N3S
114 18.530 3730253030756010075S811+N66N3S
Frame Size R
182 30 55 59 50 40 60 50 125 100 150 125 S811+R10N3S
234 40 63 80 60 50 75 60 150 125 200 150 S811+R13N3S
Frame Size T
311 51 90 110 100 75 100 100 250 200 250 250 S811+T18N3S
415 75 110 147 125 100 125 125 300 250 300 300 S811+T24N3S
526 90 160 185 150 125 150 150 400 300 400 400 S811+T30N3S
Frame Size U
623 110 185 220 200 150 250 200 450 400 550 450 S811+U36N3S
727 129 220 257 250 200 300 250 550 450 700 550 S811+U42N3S
865 150 257 300 250 250 300 250 600 550 750 700 S811+U50N3S
Frame Size V
623 110 185 220 200 150 250 200 450 400 550 450 S811+V36N3S
727 129 220 257 250 200 300 250 550 450 700 550 S811+V42N3S
865 150 257 300 250 250 300 250 600 550 750 700 S811+V50N3S
1125 200 355 425 400 300 400 300 750 700 900 750 S811+V65N3S
1246
11 111111111
S811+V72N3S
1471
11 111111111
S811+V85N3S
1 11 111111111
S811+V10N3S
