Appendix A—Parameters
50 S811+ Soft Starter MN03900001E—November 2012
Protection Menu
Protections Menu—All Catalog Numbers
Fault Code Protections Menu Units Minimum Maximum Default Notes
14 Overload Fault Enable 0 2 1 0 = Disable
1 = Enable
2 = Warning
*Ovld On Start 011 0 = Disable
1 = Enable
* Motor Rated Volt volts 115 600 480
volts 115 690 480 690 volt option
42 Low Volt Trip Enable 0 2 1 0 = Disable
1 = Enable
2 = Warning
Low Volt Level % 1 99 90
Low V Trip Dly seconds 1 60 3
43 Hi Volt Trip—Enable 0 2 0 0 = Disable
1 = Enable
2 = Warning
Hi Volt Level % 101 120 110
Hi V Trip Dly seconds 1 60 3
7 V Imbal Trip Lev % 1 100 6
V Imbal Trip Dly seconds 1 60 0.5
6 Phase Loss Fault 0 2 1 0 = Disable
1 = Enable
2 = Warning
Phase Loss % Trp % 1 100 80
Ph Loss Trip Dly seconds 1 60 0.5
9 Lo I Trip Enable 0 2 1 0 = Disable
1 = Enable
2 = Warning
Low I Trip % FLA % 0 100 6
Lo I Trip Delay seconds 1 60 2
7 Phase Imb Fault—Enable 0 2 1 0 = Disable
1 = Enable
2 = Warning
I Imbal Trip Lev % 1 100 40
I Imbal Trip Dly seconds 1 60 0.5
11 Jam Fault—Enable 0 2 1 0 = Disable
1 = Enable
2 = Warning
63 Stall Fault—Enable 0 2 1 0 = Disable
1 = Enable
2 = Warning
To Next Page
