Eaton S811+V36 series User Manual

Appendix A—Parameters
52 S811+ Soft Starter MN03900001E—November 2012
Parameter List—Advanced I/O Setup—All Catalog Numbers, continued
Advanced I/O
Setup Menu Units Minimum Maximum Default Notes
Access
Level
Relay Config Entry 0 = Terminals 13, 14 0 10 3 0 = No Function
1 = Fault
2 = Fault NOT
3 = Bypassed
4 = Bypassed NOT
5 = Motor Energized
6 = Motor Energized NOT
7 = Warning
8 = Warning NOT
9 = Custom Flt/Warn
10 = Custom Flt/Warn NOT
2
Entry 1 = Terminals 95, 96, 98 0 10 1
Entry 2 = Network Output 1 0 10 0
Entry 3 = Network Output 2 0 10 0
Relay Custom Cfg User-Entered Fault Warning
Codes
——— 2
Pwr On Start Dly Seconds 0 60 0 2
Start Delay Seconds 0 60 0 2
Run Chg Strt Dly Seconds 0 60 0 2
Start Delay Warn 0 1 1 0 = Disable
1 = Enable
2
R2 Phase Seq 0 1 0 0 = ABC
1 = ACB
2
R2 Start Method 0 3 0 0 = Voltage Ramp
1 = Current Limit
2 = Unavailable
3 = Pump Start (Opt.)
2
R2 Initial Torq % 0 85 45 1
R2 Soft Start Tm Seconds 5 180 20 1
R2 Kick St Torq % 0 85 0 1
R2 Kick St Time Seconds 0 2 0 1
R2 Pump Stop Tm Seconds 20 120 60 1
R2 Soft Stop Tm Seconds 0 60 0 1
Analog Input Flt 0 2 0 0 = Disable
1 = Enable
2 = Warning
2
Analog Low Trip % 0 100 10 2
Analog High Trip % 0 100 90 2
Analog Trip Dly Seconds 1 60 3 2
Analog In Range 2 3 3 2 = 0–20.0 ma DC
3 = 4.0–20.0 ma DC
2
Analog In Sense % 0
Analog In Status 0
