Eaton S811+V36 series User Manual

Appendix D—Ratings, Cooling and Power Losses—Inside-the-Delta
S811+ Soft Starter MN03900001E—November 2012 61
Severe Duty—30 Second Ramp and/or 450% Current Limit at 50°C—Inside-the-Delta Connection
Notes
1.0SF = 1.0 Service Factor.
1.15SF = 1.15 Service Factor.
1
Consult factory.
Maximum
Continuous
Line Current
Three-Phase Motors
Catalog
Number
kW Rating (50 Hz) hp Rating (60 Hz)
230V 380–400V 440V 200V 230V 460V 575–690V
1.0SF 1.0SF 1.0SF 1.0SF 1.15SF 1.0SF 1.15SF 1.0SF 1.15SF 1.0SF 1.15SF
Frame Size N
39 5.5 10 11 7.5 7.5 10 7.5 25 15 30 25 S811+N37N3S
73 1118.5221515251550406050S811+N66N3S
Frame Size R
111 15 30 33 25 25 30 25 75 60 75 75 S811+R10N3S
138 22 40 45 40 30 50 40 100 75 125 100 S811+R13N3S
Frame Size T
199 33 59 63 50 50 60 50 125 125 150 150 S811+T18N3S
257 45 80 90 75 60 75 75 150 150 250 200 S811+T24N3S
324 55 100 110 100 75 100 100 250 200 300 250 S811+T30N3S
Frame Size U
415 75 110 147 125 100 125 125 300 250 300 300 S811+U36N3S
526 90 160 185 150 125 150 150 400 300 450 400 S811+U42N3S
623 110 185 220 200 150 250 200 450 400 550 450 S811+U50N3S
Frame Size V
415 75 110 147 125 100 125 125 300 250 300 300 S811+V36N3S
526 90 160 185 150 125 150 150 400 300 450 400 S811+V42N3S
623 110 185 220 200 150 250 200 450 400 550 450 S811+V50N3S
727 129 220 257 250 200 250 250 550 450 700 550 S811+V65N3S
816 147 257 295 250 250 300 250 600 550 750 700 S811+V72N3S
908 160 280 335 250 250 300 250 700 550 750 700 S811+V85N3S
1 11 111111111
S811+V10N3S
