Eaton VICKERS SystemStak - Pilot Operated Check Valve Installation Dimensions; General Dimensions

Installation Dimensions in mm (inches)
A(A1)
P
B(B1)
T
A
P
B
T
A
P
B
T
40
(1.57)
3,5 (0.14)
Ø3 (0.12 dia)
47,6
(1.87)
46
(1.8)
39 (1.54)
76 (3)
4 off “O” seals supplied for this mounting face
4 holes through: Ø5,3 (0.21 dia)
101 (4) max.
13
(0.51)
97 (3.82)
13
(0.51)
97 (3.82)
12 (0.47)
23
(0.9)
DGMPC-3-(D)AB*-(D)BA*-4* DGMPC-3-(D)AB*-4*
DGMPC-3-(D)BA*-4*
18
