6 EATON Vickers Solenoid Operated Directional Valves Product Catalog V-VLDI-MC011-E September 2008
Model Code
DG4V—3(S)—** *(L)—(**)—(V)M—(S*)—* ** * D* (L)—* *—6*—(EN***)—(P**—A**—B**—T**)
15
Port T code
Refer to “Operating Data” for
port T pressure ratings.
2 – 10 bar (150 psi) for spool
position indicator models
S3, S4 and S5.
4 – 70 bar (1000 psi)
5 – 100 bar (1500 psi) for stan-
dard performance models,
DG4V-3S, with AC or DC
solenoids.
6 – 207 bar (3000 psi) for AC
high performance models,
DG4V-3, including spool
position indicator type S6.
7 – 207 bar (3000 psi) for DC
high performance models,
DG4V-3, including spool
position indicator type S6.
16
Design number
60 – Basic design
61 – Type 8 spool
17
Special features
“EN***” code number
assigned as required.
EN21 – CSA approved models
with 1/2” NPT entry
conduit box, type FW
and solenoid coil letter
B,D,G, or H.
18
Port restrictor plugs
For details of plug orifice sizes
and how to specify in model
code see page 15. May be
fitted to valves by agreement
with your Eaton representative.
Omit – No restrictor plugs
fitted
7654321 8 9 1210 1311 14 1615 1817
