13EATON Vickers Solenoid Operated Directional Valves Product Catalog V-VLDI-MC011-E September 2008
Installation
Dimensions
Models with “F” type coils (lead wires) and conduit box.
Double solenoid models s
DG4V-3(S)-*C-**-(V)M-F-**-60
DG4V-3(S)-*N-**-(V)M-F-**-60
Single solenoid models
s
DG4V-3(S)-*A(-**)
l
DG4V-3(S)-*B(-**)
l
DG4V-3(S)-8BL(-**)
DG3V-3(S)-*F
l
DG4V-3(S)-*AL(-**)l
DG4V-3(S)-*BL(-**)
l
DG4V-3(S)-8B(-**)
DG4V-3(S)-*FL(-**)
l
Dimensions in mm(in).
As
shown
Spolenoid
and end cap
interchanged
Model type AC or DC A Dim. B Dim. C Dim. D Dim.
All DC = 220 (8.66) 156,5 (6.14) 61 (2.5) 73 (2.87)
DG4V-3 AC ~ 200 (7.87) 146,5 (5.75) 51 (2.1) 63 (2.48)
DG4V-3S AC ~ 200 (7.87) 146,5 (5.75) 45 (1.7) 63 (2.48)
l Not applicable to type “8” spool. s See page 24 for solenoid information.
Codes “FJ” and “FW”: 2 lead wires for each solenoid, approximately 150,00 (6.00) long. M3 (#6)
terminals provided for customer connection.
Codes “FTJ” and “FTW”: Valve supplied with lead wires connected into terminal strip suitable
for M3 (#6) terminals for customer connection.
47
(1.85)
Ground
connection
4,0 (0.16 dia.)
self–tapping
screw
Two lead
wires per
solenoid with
M3 size
terminals for
customer
connections
24,00
(0.94)
25,00
(0.98)
3,0
(0.12)
*J & W conduit boxes
Thread connection
“W”– NPT
“J”– M20 × 1.5-8H
91,00
(3.57)
21,75
(0.86)
48,00
(1.88)
50,00
(2.0)
A (double solenoid models)
B (single solenoid models)
C coil
length
D
74,00
(2.91)
68,75
(2.71)
53,00
(2.1)
Port A
Port P
Port T
Port B
* 89 (3.5) for FPB – J & W conduit boxes
104 (4.0) All plug-in conduit boxes
