9 Technical data
9.5 Interfaces
60 MICRO PANEL XVS400 10.4"/12.1"/15" 10/2011 MN04802012Z-EN www.eaton.com
9.5 Interfaces
Tab. 27 Interfaces
9.5.1 Power supply
Property XVS400 10.4"/12.1"/15"; MS2 10.4"/12.1"
Ethernet 100Base-TX / 10Base-T
System Port RS232, not electrically isolated
USB Host 2 × USB 2.0 (1.5 / 12 Mbit/s),
not electrically isolated
USB Device USB 1.1, not electrically isolated
Profibus Profibus, electrically isolated, max. 1.5 Mbit/s
Power supply → Chapter 9.5.1, 60
DIAG Only for service tasks
Property XVS400 10.4"/12.1"/15"; MS2 10.4"/12.1"
Rated voltage 24 VDC SELV (safety extra low voltage)
Permissible voltage
RMS value:
20.4… 28.8 VDC
(rated voltage -15 % / +20 %)
Absolute with ripple:
19.2 … 30.0 VDC
35 VDC for a period < 100 ms
Voltage dips
10 ms from rated voltage (24 VDC)
5 ms from undervoltage (20.4 VDC)
Power consumption
10.4" and 12.1" devices
Basic device Max. 18 W (normally 14 W)
USB stations on USB host 2 × max. 3 W
Total Max. 24 W
15" devices
Basic device Max. 30 W (normally 28 W)
USB stations on USB host 2 × max. 3 W
Total Max. 36 W
