18
Removing the Lens
Repeat steps 1-4 for the other side, and then remove the mid-
section lens(es).
Locate the lens latch on one end of the lightbar. Turn the latch
90° counter clockwise to release.
Tip: Where the end and mid-section lenses meet, gently press
both sides of the end lens inward to release the retaining
clips.
Tilt and lift the end lens to remove it from the chassis.
1 2
3
4
Open
Position
Retaining
Clip
To Next Page
