26
Alley Light Modules
EZ1403AL
The EZ1403AL LED alley light module provides high-intensity scene lighting to the left and/or right of the vehicle. Install these
modules in the center DropLock
TM
power rail, only. Press the left and/or right alley light button(s) on the keypad controller to
operate these modules.
Remove the lenses to access the DropLock
TM
power rail system.
Install the alley light base in the center power rail. The alley
light is intended for side illumination and should be placed
only in the location shown above.
If necessary, rotate the top of the module to aim the beam
of light as desired. It does not matter which way the contact
indicators are facing.
1 2
FRONT
