25ENGLISH
WARNING
There is a four (4) module maximum per worklamp button on the keypad controller. Do not attempt
to install worklamps in the front or rear power rails as damage to the central control board can occur.
Apply power to the lightbar
and use the front and rear
worklamp buttons on the
keypad to operate.
ASSEMBLY &
CONFIGURATION
Worklamp
Module Installation
If necessary, rotate the top
of the module to the desired
angle.
3
To secure the module in
the power rail, turn the
locking knob clockwise a half
turn. Install any additional
modules, and replace the
lens.
4
5
