21ENGLISH
CERTIFICATIONS
The image above depicts the minimum required conguration to meet SAE J845 Class I, ECE R65, and
California Title 13. The location of the directional modules directly affects compliance with industry
standards and regulations. They must be mounted in approved locations at a 45º angle.
FRONT
Apply power to the lightbar and press the
power button on the keypad to turn on the
directionals. Use the SEL and power buttons
to set ash pattern presets.
To secure the module in the power rail, turn
the locking knob clockwise a half turn. Install
any other additional modules, and replace the
lens.
3
4
ASSEMBLY &
CONFIGURATION
Directional
Module Installation
To Next Page
