L I Q U I D C R Y S T A L D I S P L A Y
LCD Lift Status
The lift status is shown to the top right centre of the LCD display.
The left side example shows the lift Running Down
• BDL Bridged door lock. Doors shall remain open until bridge is removed. See DFOF/DFOR input
• DCP Fail door close protection. See DFCF/DFCR input
• DOP Fail door open protection. See DFOF/DFOR input
• IDL Lift idle
• LCK Door Locks not made. See DFCF/DFCR input
• LDN Leveling down, displays on re-level down. See MSU input
• LEV Leveling blocked, displays on re-leveling failed and disabled. See MSD/MSU input
• LRN Learning floor operation in progress.
• LUP Leveling up, displays on re-level up. See MSD input
• PRV Waiting PRV input to run. See PRV input
• RDN Running down
• RPT Run protection time exceeded. Fatal error. See EEprom settings - RPT
• RUP Running up
• SAF Lost safety circuit. See SAF input
LCD Door Modes
The door modes for both front and rear are shown to the top right of the LCD
display with the front door mode is on the left and the rear door is on the right.
The above example shows the front doors are closing whereas the rear doors are already closed.
The front and rear door modes will be shown separately with these following statuses:
• <> Doors opening
• [] Doors open
• >< Doors closing
• ][ Doors closed
But both of them will be commonly shown at one with these following statuses:
• -bad Doors fully closed but door locks not made. See DFC input
• -fail Doors failed on DOP or DCP. See DFC/DFO input
• - - Doors on other control. ie – Inspection.
The left side example shows both the front door and rear door are having doors
fully closed signal, but door locks have not made.
02d NOR RDN ][][
ECD Aust. V-4.02
02- NOR LCK ><][
ECD Aust. V-4.02
02- NOR LCK -bad
ECD Aust. V-4.02
