Echo BEAR CAT EGI-2000

30
EntrEtIEn
3332
Inverter Generator Owner's Manual
Maintenance
1. Remove the screws and then
pull outward on the areas of the
cover shown.
2. Loosen the bolt and then
remove the muffler cap , the
muffler screen and spark
arrester .
3. Clean the carbon on the muffler
screen by wire brush.
①
②
③
④
⑤
⑥
，
!
WARNING
4. Check the muffler screen and
spark arrester, replace if it
damage.
5. Install spark arrester.
NOTICE
When cleaning, use the
wire brush lightly to
avoid damaging or
scratching the muffler
screen and spark
arrester.
If using in areas prone
to fires such as forest
or woods, never use
an engine without an
appropriate spark
arrester.
Align the spark arrester
projection with the hole in
the muffler pipe.
TIP:
⑦⑧
6. Install the muffler screen and the
muffler cap.
7. Install the cover and tighten the
screws.
Inverter Generator Owner's Manual
Maintenance
1. Remove the fuel tank cap
and filter.
2. Clean the filter with gasoline.
3. Wipe the filter and install it.
4. Install the fuel tank cap.
!
WARNING
Never use gasoline
while smoking or in the
vicinity of an open
flame.
FUEL TANK FILTER
Be sure the fuel tank cap is
tightened securely.
1. Remove the screws , and then
remove the cover drain the
fuel .
2. Hold and move up the clamp ,
then take off the hose from
the tank.
3. Take out the fuel filter .
4. Clean the filter with gasoline.
5. Dry the filter and replace.
6. Install the hose and clamp, then
open the fuel valve to check for
leaks.
7. Install the cover and tighten the
screws.
①
②
③
④
⑤
⑥
，
FUEL FILTER
3332
Inverter Generator Owner's Manual
Maintenance
1. Remove the screws and then
pull outward on the areas of the
cover shown.
2. Loosen the bolt and then
remove the muffler cap , the
muffler screen and spark
arrester .
3. Clean the carbon on the muffler
screen by wire brush.
①
②
③
④
⑤
⑥
，
!
WARNING
4. Check the muffler screen and
spark arrester, replace if it
damage.
5. Install spark arrester.
NOTICE
When cleaning, use the
wire brush lightly to
avoid damaging or
scratching the muffler
screen and spark
arrester.
If using in areas prone
to fires such as forest
or woods, never use
an engine without an
appropriate spark
arrester.
Align the spark arrester
projection with the hole in
the muffler pipe.
TIP:
⑦⑧
6. Install the muffler screen and the
muffler cap.
7. Install the cover and tighten the
screws.
Inverter Generator Owner's Manual
Maintenance
1. Remove the fuel tank cap
and filter.
2. Clean the filter with gasoline.
3. Wipe the filter and install it.
4. Install the fuel tank cap.
!
WARNING
Never use gasoline
while smoking or in the
vicinity of an open
flame.
FUEL TANK FILTER
Be sure the fuel tank cap is
tightened securely.
1. Remove the screws , and then
remove the cover drain the
fuel .
2. Hold and move up the clamp ,
then take off the hose from
the tank.
3. Take out the fuel filter .
4. Clean the filter with gasoline.
5. Dry the filter and replace.
6. Install the hose and clamp, then
open the fuel valve to check for
leaks.
7. Install the cover and tighten the
screws.
①
②
③
④
⑤
⑥
，
FUEL FILTER
3332
Inverter Generator Owner's Manual
Maintenance
1. Remove the screws and then
pull outward on the areas of the
cover shown.
2. Loosen the bolt and then
remove the muffler cap , the
muffler screen and spark
arrester .
3. Clean the carbon on the muffler
screen by wire brush.
①
②
③
④
⑤
⑥
，
!
WARNING
4. Check the muffler screen and
spark arrester, replace if it
damage.
5. Install spark arrester.
NOTICE
When cleaning, use the
wire brush lightly to
avoid damaging or
scratching the muffler
screen and spark
arrester.
If using in areas prone
to fires such as forest
or woods, never use
an engine without an
appropriate spark
arrester.
Align the spark arrester
projection with the hole in
the muffler pipe.
TIP:
⑦⑧
6. Install the muffler screen and the
muffler cap.
7. Install the cover and tighten the
screws.
Inverter Generator Owner's Manual
Maintenance
1. Remove the fuel tank cap
and filter.
2. Clean the filter with gasoline.
3. Wipe the filter and install it.
4. Install the fuel tank cap.
!
WARNING
Never use gasoline
while smoking or in the
vicinity of an open
flame.
FUEL TANK FILTER
Be sure the fuel tank cap is
tightened securely.
1. Remove the screws , and then
remove the cover drain the
fuel .
2. Hold and move up the clamp ,
then take off the hose from
the tank.
3. Take out the fuel filter .
4. Clean the filter with gasoline.
5. Dry the filter and replace.
6. Install the hose and clamp, then
open the fuel valve to check for
leaks.
7. Install the cover and tighten the
screws.
①
②
③
④
⑤
⑥
，
FUEL FILTER
Le moteur ne doit jamais fonctionner sans cartouche en mousse,
il en résulterait une usure excessive du piston et du cylindre.
7. Remettez le couvercle du boîtier du filtre à air dans sa position
d’origine, puis serrez la vis.
8. Installez le couvercle et serrez les vis.
ÉCRAN DU SILENCIEUX ET PARE-ÉTINCELLES
ATTENTION
• Le moteur et le silencieux sont très chauds après le fonctionnement
du moteur. Évitez de toucher le moteur ou le silencieux pendant qu’ils
sont encore chauds avec n’importe quelle partie de votre corps ou
vos vêtements pendant l’inspection ou la réparation.
1. Retirez les vis (1), puis tirez sur le couvercle vers l’extérieur (2), comme
illustré.
2. Desserrez la vis (3), puis retirez le bouchon du silencieux (4), l’écran
du silencieux (5) et le pare-étincelles (6).
3. Nettoyez les dépôts de carbone sur l’écran du silencieux et le pare-
étincelles à l’aide d’une brosse métallique.
AVIS
• Lors du nettoyage, ne frottez pas
trop fort avec la brosse métallique
pour éviter d’endommager ou de
rayer l’écran du silencieux ou le pare-
étincelles.
4. Vérifiez l’écran du silencieux et le pare-étincelles. Remplacez-les s’ils
sont endommagés
5. Installez le pare-étincelles.
