20
6.3 Alternating Current (AC) connection
WARNING
•
them in.
NOTICE
• Be sure all electric devices including the lines and plug connections are
in good condition before connection to the generator.
• Be sure the total load is within generator rated output.
• Be sure the receptacle load current is within receptacle rated current.
• The generator (STATOR WINDING) is isolated from the AC receptacle
ground pin.
• Electrical devices that require a grounded receptacle pin connection will
not function if the receptacle ground pin is not functional.
TIP: Make sure to ground (Earth) the generator. When the electrical
device is grounded, the generator must also be grounded.
1. Start the engine.
2. Turn the ESC to “ON”.
3. Plug in to AC receptacle.
4. Make sure the AC pilot light is on.
5. Turn on any electric devices.
TIP: The ESC must be turned to “OFF” to increase engine speed to
rated rpm. If the generator is connected to multiple loads or electricity
starting current and last connect the one with the lowest starting
current.
6.4 Battery Charging
TIP:
• The generator DC rated voltage is 12V.
•
for charging.
• Before starting to charge the battery, make sure that the DC
protector is turned on.
1. Start the engine.
2. Connect the red battery charger lead to the positive (+) battery
terminal.
3. Connect the black battery charger lead to the negative (-) battery
terminal.
4.
OPERATION
