28
1200I
6. Add engine oil to the upper level.
Recommended engine oil: SAE 10W30
Recommended engine oil grade: API Service SE type or higher
Engine oil quantity: 0.31L
7. Wipe the cover clean, and wipe up any spilled oil.
NOTICE
• Be sure no foreign material enters the crankcase.
9. Install the cover and tighten the screws.
7.4 Air lter
1. Remove screws (1), and then remove cover (2).
2.
3. Remove foam element (5).
4. Wash the foam element in solvent and dry it.
5. Oil the foam element and squeeze out excess oil.
The foam element should be wet but not dripping.
TIP: Be sure the foam element sealing surface matches
MAINTENANCE
