33
SPECIFICATIONS
Engine Model R60-i
Start Manual
Rated Frequency 60Hz
Rated Voltage 120V
Rated Power 1KW
DC Output 12V, 5A
Fuel Tank Capacity 2.6L
Full Load Continuum Running Time 3.5h
50% Load Continuum Running Time 5.2h
Noise (7m) 64dB
1 x Duplex, Parallel
socket, 2 x USB outlets
CSA/EPA/CARB
LOW THD N/A
Wheels & Kits N/A
10. SPECIFICATIONS
Instructions: First, connect the 2 inverters with 2 parallel cables as per
the drawing above, and then start the inverters one at a time. At this
time, the total rated power will be 2000W.
Note: Ensure the cables are connected to the inverters correctly. If they
are connected incorrectly, the inverters will not output any power and
connected.
Example of 2x 1200 watt units paralled
11. PARALLEL FUNCTION INSTRUCTIONS
