34
12. DIAGRAMA DE CABLEADO
DIAGRAMA DE CABLEADO
Toma de corriente
Bloque generador
Bobina de
encendido
carga

Bloque inversor
inversor
Sensor de aceite
Ignición Bujia Motor paso a paso
BLOQUE MOTOR
Panel de control
Interruptor ESC
Luz piloto de CA
Indicador de sobrecarga
Enchufe DC
Interruptor de extinción
Luz de advertencia
de aceite
Azul
Cafe
Verde / Amarillo
Rojo / Blanco
Rojo
Negro
Blanco
Naranja
