22
6.5 Application range
When using the generator, make sure the total load is within rated output of a
generator. Otherwise, damage to the unit may occur.
AC
Power
Factor
1 0.8-0.95 0.4-0.75
0.85)
Rated
output
power
EGi-1200
1,000W 800W 400W
Rated
voltage 12V
TIP:
• Application wattage indicates when each device is used by itself.
• The simultaneous usage of AC and DC power is possible but total wattage
should not exceed the rated output.
EX:
The overload indicator (1) comes on when total wattage exceeds the
application range. (See page 11 for more details.)
Generator rated output EGi-1200
Frequency Power factor
AC
1.0 1100W
0.8 880W
DC --- 60W
(12V/5A)
OPERATION
To Next Page
