PPF-225 SPECIFICATIONS
X7502308206 35
©7/2015 ECHO Inc.
SPECIFICATIONS
This spark ignition system complies with the Canadian standard ICES-002.
MODEL PPF-225
Length 2,455 m (96.7 in.)
Width 246 m (9.69 in.)
Height 235 m (9.25 in.)
Weight (dry) 6.3 kg (13.9 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.27 in.)
Stroke 26.0 mm (1.02 in.)
Displacement 21.2 cc (1.29 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPMR-8Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X
TM
or ECHO Red Armor
®
ISO-L-EGD (ISO/CD 13738) and J.A.S.O.
M345- FD, two-stroke, air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl
alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X
TM
or ECHO Red Armor
®
Premium Universal 2-Stroke Oil
Fuel Tank Capacity 0.44 lit. (14.9 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft 6.35 mm (1/4 in.) flexible shaft
Sprocket Type 6 tooth spur, 9.53 mm (3/8 inch) pitch
Shaft Tube Assembly 25 mm (1 in.) Galvanized Steel
Gear Case Ratio 1.53
Oiling System Automatic
Chain Oil Capacity .2 L (6.76 oz.)
Handles Right hand grip w/throttle trigger and throttle trigger lockout / Left foam hand grip
Shoulder Harness Standard
Idle Speed 2,750 RPM
Clutch Engagement Speed 4,300 RPM
Wide Open Throttle Speed (W.O.T.) 10,900 RPM
Guide Bar and Saw Chain (91) 254 mm (10 in.); 9.53 mm (3/8 inch) pitch chain, 0.050 gauge
