OPERATION PPF-225
28 X7507820701
© 09/19 ECHO Incorporated
Stopping Engine
1. Throttle
Release throttle trigger and
allow engine to return to idle
before shutting off engine.
2. Stop Switch
Move stop switch button (A)
backward to STOP position.
If engine does not stop when stop switch is moved to STOP
position, close choke - COLD START position - to stall engine.
Have your ECHO dealer repair stop switch before using unit
again.
Pruning Techniques
Shoulder Harness (if included)
1. Loosen the harness clamp
screw (A).
2. Put the harness on and attach it
to the clamp ring (B).
3. Adjust harness for comfortable
operation.
4. Tighten harness clamp screw
(A).
The pole pruner attachment is designed for light to medium trimming of
limbs and branches up to 203 mm (8 in.) diameter. Follow these tips for
successful operation.
