PPF-225 MAINTENANCE
X7507820701 35
© 09/19 ECHO Incorporated
Cooling System
Level 2.
To maintain proper engine operating temperatures, cooling air must
pass freely through the cylinder fin area. This flow of air carries
combustion heat away from the engine.
Overheating and engine seizure
can occur when:
• Air intakes are blocked,
preventing cooling air from
reaching the cylinder.
• Dust and grass build up on the
outside of the cylinder. This build
up insulates the engine and
prevents the heat from leaving.
Removal of cooling passage
blockages or cleaning of cooling
fins is considered “Normal
Maintenance.” Any failure
attributed to lack of maintenance is
not warranted.
1. Remove spark plug lead.
2. Close choke (COLD START
[ ] position). This prevents
dirt from entering the
carburetor throat when the air
filter is removed. Remove air
cleaner cover (A).
3. Remove engine cover (B).
To Next Page
