PPF-225 SPECIFICATIONS
X7507820701 49
© 09/19 ECHO Incorporated
Fuel/Oil Ratio 50 : 1
Gasoline
Use 89 Octane unleaded. Do not use fuel containing
methyl alcohol, more than 10% ethyl alcohol or 15%
MTBE. Do not use alternative fuels such as E15 or
E85.
Oil
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345-
FD
, two-stroke, air-cooled engine oil
Fuel Tank Capacity 0.44 L (14.9 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft 6.35 mm (1/4 in.) flexible shaft
Shaft Tube Assembly 25.4 mm (1 in.) Galvanized Steel
Gear Case Ratio 1.53 : 1
Oiling System Automatic
Chain Oil Capacity 197 ml (6.6 oz.)
Handles Right hand grip w/throttle trigger and throttle trigger
lockout / Left foam hand grip
Shoulder Harness Standard
Idle Speed 3,000 RPM
Clutch Engagement Speed 4,300 RPM
Wide Open Throttle Speed
(W.O.T.)
10,900 RPM
Guide Bar and Saw Chain
(91)
254 mm (10 in.); 9.53 mm (3/8 inch) pitch chain,
0.050 gauge
MODEL PPF-225
