Echo SRM-266 User Manual

SRM-266
MAINTENANCE
X7502028004 43
© 02/21 ECHO Incorporated
Nylon Line Replacement
Wear gloves or personal injury may result:
◆ Cutoff knife is sharp.
◆ Gearcase and surrounding area may be hot.
Never use wire or wire-rope that can break off and become a
dangerous “projectile”. Serious injury can occur.
1. Cut one piece of line to
recommended length.
2.0 mm (0.080 in.) diameter
6 m (20 ft.).
2.4 mm (0.095 in.) diameter
6 m (20 ft.).
2. Align arrows on top of knob with
openings in eyelets.
3. Insert one end of trimmer line
into an eyelet, and push line
equal distance through trimmer
head.

Echo SRM-266 Specifications

General

Engine Displacement	25.4 cc
Fuel Capacity	16.9 fl. oz.
Cutting Swath	17 inches
Shaft Type	Straight
Starting System	i-30™ starting system
Engine Type	2-stroke
Warranty	2 years
