2-2. 8/16 Channel Premium DVR
The rear panels of the 6/18 channel premium DVR comprise the following:
[8 Channel Premium Model]
[16 Channel Premium Model]
• Front USB: Two USB ports are provided to connect external devices like HDD, Flash memory
for Backup, System upgrade or USB mouse on the front panel. A USB mouse can be connected
only front panel USB port dedicated only for mouse.
Video Input
Connect the coaxial cables from the cameras to the BNC video connectors.
Loop-Through Video
Connect the coaxial cables from the Loop BNC connector to another device.
Note
: To use Loop option, additional looping cable will be needed. Please
contact your supplier.
Audio Input
The DVR can record audio up to 8 sources. Connect the audio sources to
the Audio-In Multi-connectors. All channels need external pre-amplifiers.
It is the user's responsibility to determine if local laws and regulations
permit recording audio.
