100
About the optional unit
Others
About the opti onal unit
Connecting a portable audio
player to the AUX jack
Use a commonly available accessory cable with
an RCA connector or an optional AUX105 to
connect a portable audio player to the AUX
(auxiliary) jack of this system.
There are 2 connection terminals on this main
unit; one for the RCA connector and the other for
the optional LAN cable (AUX 105). The default
setting for AUX is OFF.
The AUX mode is activated.
For details, refer to "Switching Audio
Modes" on page 18.
ATTENTION
• While the AUX mode is activated, actions
such as turning off the audio player or
pulling out the connection cord may cause
noise spikes that can damage the system
speakers. Be sure to avoid this possibility
by turning off system power or switching
from the AUX mode to another mode before
shutting off or disconnecting the portable
audio player.
• Audio output levels for the various devices
that can be connected using this method
will differ. Carefully adjust the volume until
the output level of the connected player is
known.
• Before using a portable audio player in a
vehicle, read the player's operation manual
carefully and confirm problem-free
operation in the vehicle before proceeding.
• When you connect an optional LAN cable
(AUX 105) to the main unit, other optional
equipment that uses E-LAN cannot be
connected.
Switching the AUX mode on and off
The Menu selection mode is activated.
The function mode is activated.
The AUX ON/OFF mode is activated.
Press the button to switch the mode as
follows:
Up:
Mode is ON
Down:
Mode is OFF
The selected settings will take effect.
Switching the input system
When using an optional AUX cord (AUX105), the
main unit can be switched between RCA input
and optional AUX cord (AUX105) input.
The system will switch between RCA
input and optional AUX cord input
each time the button is pressed.
RCA input (INPUT) ↔ Optional AUX
cord (SUB INPUT)
1
Turn on the portable audio player
and start its play function.
1
Press the [ /MENU] button for
more than one second.
2
Press the [SELECT] (Up/Down)
button to select FUNC, and then
press the [ENTER] button.
3
Press the [SELECT] (Up/Down)
button to select AUX ON/OFF.
4
Press the [SELECT] (Up/Down)
button to select the ON/OFF mode.
1
Press the [MODE] button for more
than one second.
To Next Page
