Ecoflam Blu 700 PR/MD - Page 58

pag.58
B LB 381 BLU 500 -1400 PR / MD
BLU 500 PR
B DESCRIPTION code
1-AIR PRESSURE SWITCH DUNGS LGW10 A2P Q120
2-AIR INTAKE SET GRPA101
3-PLUG WIELAND 6 pin E226
4 - BURNER COVER BFC09151/011
5- GLASS BFC02004
6-PEED WINDOM FRAME BFC02006
7- MOTOR 550 W M169
8-FAN 220 x 98 BFV10155/001
9-AIR CONVEYOR BFC08202/017
10 - FAN SCOOP BFC08055/001
11 - AIR INTAKE BFC04160/011
12 - CONTROL BOX BASE
LANDIS
A402
SATRONIC A417
13 - CONTROL BOX LANDIS LGB 22 A130/1
SATRONIC DMG 972 A162/01
14 - IGNITION TRANSFORMER
COFI 1020 CM
T105/1
15 - REMOTE CONTROL SWITCH MC9.10 R603/1
16 - MOTOR THERMAL RELAY Lovato RF9 1,4-2 ,3A R510
17 - MAIN SWITCH cod.40100I1509 R1020
18 - SELECTOR R1020/5
19 - LAMP EL/N-SC4 Elettrospring E1510
20 - FUSE SUPPORT FUSIT FH-B528 E802/2
21 - RELAY BASE FINDER 5532 R905
22 - RELAY FINDER R711
23 - IONIZATION CABLE TC BFE01403/4
TL E1102/21
24 - IGNITION CABLE TC BFE01402/1
TL BFE01402/2
25 - IONIZATION PROBE BFE01032/3
26 - IGNITION ELECTRODES GREL101
27 - PRESSURE GAUGE BFT01105/001
28 - PIPE BFT13102/001
29 - ROD BFA08001/001
30 - FIRING HEAD TC BFT13101/101
TL BFT13101/201
31 - REAR DISC BFD02010/401
32 - FRONT DISC (G20) BFD06002/2
(G30-G31) BFD06001/2
33 - INNER ASSEMBLY TC GRTT0100/371
(G30-G31) TC GRTT0100/374
TL GRTT0100/372
(G30-G31) TL GRTT0100/375
34 - BLAST TUBE TC BFB04005/103
TL BFB04005/203
35 - GASKET ISOMART BFG03002/1
36 - ANTIJAMMING FILTER S132/4
37 - AIR DAMPER MOTOR LANDIS SQN 31.251A2700 M212
38 - SILENCER optional
models MD
39 -
MODULATING UNIT
LANDIS RWF 40 E1215
TC = SHORT HEAD TL = LONG HEAD
