4.4.1.4 Beverage mode – Cleaning interval reached – ‘Beer Cut’
Fig. 10: Beverage mode – Cleaning interval reached – ‘Beer Cut’
1 Cleaning intervall reached.
2 Days to the ‘Beer
-Cut’ .
3
Activates "Cleaning mode"
Ä Chapter 4.4.2 ‘Cleaning mode’ on page 23.
4
Activates "Rinsing mode"
Ä Chapter 4.4.3 ‘Rinsing mode’ on page 26.
If the cleaning interval has been reached and the ‘Beer Cut’
has also been set, the
remaining days Fig. 10, pos. 2, are also displayed. At the end of the countdown the "Alarm
– No cleaning“
Ä Chapter 4.5.3 ‘Alarm - No Cleaning’ on page 28 is activated.
4.4.2 Cleaning mode
By calling up the "Cleaning mode" function Ä Chapter 4.4.1 ‘Beverage mode’
on page 21, Fig. 8, pos. 3, the display message changes and cleaning can be started.
Fig. 11: Cleaning mode - schema 1
The "Cleaning mode" is activated by pressing [OK] key
.
The "Cleaning mode" is cancelled by pressing the [ESC] key and the display is changing
to previous display.
Fig. 12: Cleaning mode - schema 2
The water valve is opened.
Control / Visualisation
23 Rev. 04-06.2018
