5.2 Connection
Domestic water supply
CAUTION!
– The maximum permissible water pressure levels and temperatures
must be observed (see ).
If necessary
, fit a pressure reducer and/or mixing valve upstream.
– The connection for the water supply (feed line) must be located behind
a shut-off cock (angle valve).
2
3
1
Fig. 3: Connection to domestic water supply
1 Protective cap on domestic water connection
2 House water connection pipe (braided steel)
3 Spanner
1. Remove the yellow protective cap (pos. 1) from the connection.
2. Screw the house water pipe (pos. 2, braided steel pipe, not included in the scope of
delivery) to the water connection of the EcoPlus PDRX hand-tight.
3. Use two spanners (pos. 3) to tighten the braided steel pipe.
Assembly and installation
15 417102610 Rev. 01-12.2020
