Settling Rate Monitor

Installation, Operation & Maintenance Manual

By:

Nalco Water

Engineering & Project Development

February 2020

Nalco Reference No: ESTDS-STORM-IOM

Revision

Date

Comment

Prepared

Checked

Approved

K

20/02/2020

SC

DM

DM

Table of Contents

Questions and Answers:

D
Danielle ConnerJul 25, 2025
What to do if the settle timer does not record on Ecolab Nalco Water STORM Settling Rate Monitor?
- A
  Amanda HarringtonJul 26, 2025
  If the settle timer on your Ecolab Measuring Instruments isn't recording, it could be due to a few reasons. First, there might be an issue with the flocculant system. This could involve pump failure, problems with the flocculant makeup, or a line blockage. To address this, check the flocculant system operation, dosing pump operation, and test flocculant solution samples. Another potential cause is a fouled turbidity instrument. Try removing the instrument and cleaning it.
S
shepherdryanAug 4, 2025
Why sample level will not hold in cylinder in Ecolab Nalco Water STORM Settling Rate Monitor?
- T
  tleeAug 4, 2025
  If the sample level isn't holding in the cylinder of your Ecolab Measuring Instruments, there are several things you can check. Start by inspecting the settling cylinder for air leaks, making sure the top union and instrument unions are tight and that the union O-rings are installed. Also, ensure the turbidity instrument connection is airtight; if it feels loose, apply thread tape and reinstall it. Next, verify the sample line camlock is connected firmly and squarely. Finally, check the camlock female connection O-ring and replace it if it's worn or missing.

Ecolab Nalco Water STORM Settling Rate Monitor Specifications

General

Brand	Ecolab
Model	Nalco Water STORM Settling Rate Monitor
Category	Measuring Instruments
Language	English

Summary

Safety

Installation

Electrical Terminations

Control & Status Signals

Describes signals for hard-wired connection to site control systems.

Commissioning Checklist

Outlines steps for system setup and verification.

Principle of Operation

Description of Operation

Settling Rate – Flocculant Dose Control

Details how settling rate is used to control flocculant addition.

Supernatant Turbidity – Coagulant Dose Control

Explains how supernatant turbidity controls coagulant addition.

HMI Operation

Main (Home) Screen

Flocculant Control Configuration Screen

Coagulant Control Configuration Screen

Sampling Sequence Configuration Screen

System Configuration Screen

Manual Control Screen

Mode Select Screen

Control Functions

Details how to select system and pump operating modes.

Quick Start Settings for Floc control

Troubleshooting

Sample will not draw into Settling Cylinder

Lists actions for diagnosing sample draw issues.

Sample level will not hold in cylinder

Settle timer does not record

Maintenance

Cleaning and Preventative Maintenance Intervals

Turbidity Instrument Removal

Settling Cylinder Removal and Re-installation

Replacement parts

Related product manuals
