Ecom B - 7 Pressure Tests (Option)

Page 26
ecom-B
7. Pressure Tests (option)
1. Use only air or inert gas for check !
2. Respect the „Technical Rules for
Gas installations“!
Air pump
Connection hose
(Pump - Crosspiece)
Safety valve
Crospiece
ecom-B
Connection hose
(Gas system – Crospiece)
ecom
-
UNO
(only for Loading
and Tightness Test)
Squirt
Connection Squirt
or Soot pump
Connection
ecom-UNO (+)
Connection
ecom-
B (delta
p-)
Connection hose
(ecom-B/UNO –
Crospiece)
Electrical
connection
ecom-
B/UNO
Conic test stopple
or
One-pipe counter cap
or
High-pressure test
stopple
