10. Data processing
10.1. Communication
The menu „Data processing“ allows the
selection of the following functions:
Select:
This sub-menu enables to search for or
create a data record for the allocation of
measurement values (see chapter 3.).
Look at:
The recorded values of the selected data record can be viewed (see
chapter 3.).
Load data:
Possibility of data import e.g. from ecom software (available at
„www.ecom.de“ - check the transfer options of your software).
Proceed as follows:
1. Connect instrument and PC with a current RS232 cable.
2. Select “Load data“ and confirm with <OK>.
3. Answer following question with Yes (select with cursor keys).
4. Start the data transfer at the PC.
Send data:
The date record completed with values can be transferred to the PC
program using this function (procedure identical to „Load data“).
Format:
This function is normally only needed by the initial adjustment of the
instrument by the manufacturer (preparation of internal memory to
data receipt). Caution: All recorded values will get lost!
Data processing
Select
Look at
Load data
Send data
Format memory
Continue with :
↑↓
↵
↵↵
↵
