7
3 | Installation
3 – 1 Fixings
Before beginning installation, check that all fixings are supplied. The radiator should
only be wall mounted with the manufacturer’s fixings.
3 – 2 | Wall Mounting Instructions
Warning – Before switching on the appliance make sure that the radiator is
correctly fixed and is secure to the wall.
If the device is being fitted in a bathroom, the unit must not be plugged in. The
plug should be removed and the unit hardwired into a fused spur. This is a job for
a qualified electrician.
1. Choose the mounting position, respecting the minimum distances from
surrounding walls, ceilings or fixed objects shown in the diagram below: at
least 20cm from the top, 20cm from the sides, 10cm from the floor, and
60cm from the front. Mounting closer than recommended can cause
overheating of the device and damage to surrounding objects and surfaces.
